An instance of a LV2 plugin. More...

#include <LV2Block.hpp>

Inheritance diagram for Ingen::Server::LV2Block:

Collaboration diagram for Ingen::Server::LV2Block:

Classes
struct	Response

Public Member Functions
	LV2Block (LV2Plugin plugin, const Raul::Symbol &symbol, bool polyphonic, GraphImpl parent, SampleRate srate)
	Partially construct a LV2Block. More...

bool	instantiate (BufferFactory &bufs, const LilvState *state)
	Instantiate self from LV2 plugin descriptor. More...

LilvInstance *	instance ()

bool	save_state (const std::string &dir) const

BlockImpl *	duplicate (Engine &engine, const Raul::Symbol &symbol, GraphImpl *parent)
	Duplicate this Node. More...

bool	prepare_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (external) polyphony value. More...

bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new (external) polyphony value. More...

void	activate (BufferFactory &bufs)
	Activate this Block. More...

void	deactivate ()
	Deactivate this Block. More...

LV2_Worker_Status	work (uint32_t size, const void *data)

void	run (RunContext &context)
	Run block for a portion of process cycle (called from process()). More...

void	post_process (RunContext &context)
	Do whatever needs doing in the process thread after process() is called.

LilvState *	load_preset (const Raul::URI &uri)
	Load a preset from the world for this block. More...

void	apply_state (Worker worker, const LilvState state)
	Restore `state`. More...

boost::optional< Resource >	save_preset (const Raul::URI &bundle, const Properties &props)
	Save current state as preset. More...

void	set_port_buffer (uint32_t voice, uint32_t port_num, BufferRef buf, SampleCount offset)
	Set the buffer of a port to a given buffer (e.g. More...

Public Member Functions inherited from Ingen::Server::BlockImpl
	BlockImpl (PluginImpl plugin, const Raul::Symbol &symbol, bool poly, GraphImpl parent, SampleRate rate)

virtual GraphType	graph_type () const

bool	activated () const
	Return true iff this block is activated.

bool	enabled () const
	Return true iff this block is enabled (not bypassed). More...

void	set_enabled (bool e)
	Enable or disable (bypass) this block. More...

virtual void	learn ()
	Learn the next incoming MIDI event (for internals)

virtual void	pre_process (RunContext &context)
	Do whatever needs doing in the process thread before process() is called.

virtual void	process (RunContext &context)
	Run block for an entire process cycle (calls run()). More...

virtual Node *	port (uint32_t index) const

virtual PortImpl *	port_impl (uint32_t index) const

virtual PortImpl *	port_by_symbol (const char *symbol)
	Get a port by symbol. More...

std::set< BlockImpl * > &	providers ()
	Blocks that are connected to this Block's inputs. More...

std::set< BlockImpl * > &	dependants ()
	Blocks that are connected to this Block's outputs. More...

virtual void	set_polyphonic (bool p)
	Flag block as polyphonic. More...

virtual const Resource *	plugin () const
	Information about the Plugin this Block is an instance of. More...

virtual const PluginImpl *	plugin_impl () const
	Information about the Plugin this Block is an instance of. More...

virtual void	plugin (PluginImpl *pi)

virtual void	set_buffer_size (RunContext &context, BufferFactory &bufs, LV2_URID type, uint32_t size)

GraphImpl *	parent_graph () const
	The Graph this Block belongs to. More...

uint32_t	num_ports () const

virtual uint32_t	polyphony () const

Mark	get_mark () const

void	set_mark (Mark m)

Public Member Functions inherited from Ingen::Server::NodeImpl
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

const Raul::Path &	path () const

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Static Public Member Functions
static LilvState *	load_state (World *world, const std::string &path)

Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Protected Types
typedef Raul::Array< SPtr< void > >	Instances

typedef boost::intrusive::slist< Response, boost::intrusive::cache_last< true >, boost::intrusive::constant_time_size< false > >	Responses

Protected Member Functions
SPtr< LilvInstance >	make_instance (URIs &uris, SampleRate rate, uint32_t voice, bool preparing)

LilvInstance *	instance (uint32_t voice)

Protected Member Functions inherited from Ingen::Server::BlockImpl
PortImpl *	nth_port_by_type (uint32_t n, bool input, PortType type)

Protected Member Functions inherited from Ingen::Server::NodeImpl
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Static Protected Member Functions
static LV2_Worker_Status	work_respond (LV2_Worker_Respond_Handle handle, uint32_t size, const void *data)

Protected Attributes
LV2Plugin *	_lv2_plugin

Instances *	_instances

Instances *	_prepared_instances

const LV2_Worker_Interface *	_worker_iface

std::mutex	_work_mutex

Responses	_responses

SPtr< LV2Features::FeatureArray >	_features

Protected Attributes inherited from Ingen::Server::BlockImpl
PluginImpl *	_plugin

Raul::Array< PortImpl * > *	_ports
	Access in audio thread only.

uint32_t	_polyphony

std::set< BlockImpl * >	_providers
	Blocks connected to this one's input ports.

std::set< BlockImpl * >	_dependants
	Blocks this one's output ports are connected to.

Mark	_mark
	Mark for graph compilation algorithm.

bool	_polyphonic

bool	_activated

bool	_enabled

Protected Attributes inherited from Ingen::Server::NodeImpl
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Additional Inherited Members
Public Types inherited from Ingen::Server::BlockImpl
enum	Mark { UNVISITED, VISITING, VISITED }
	Mark used during graph compilation.

Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Detailed Description

An instance of a LV2 plugin.

Constructor & Destructor Documentation

§ LV2Block()

Ingen::Server::LV2Block::LV2Block	(	LV2Plugin *	plugin,
		const Raul::Symbol &	symbol,
		bool	polyphonic,
		GraphImpl *	parent,
		SampleRate	srate
	)

Partially construct a LV2Block.

Object is not usable until instantiate() is called with success. (It will crash!)

References Ingen::Server::BlockImpl::_ports, Ingen::Server::Buffer::nframes(), Ingen::Server::BlockImpl::parent_graph(), and Ingen::Resource::type().

Referenced by duplicate().

Member Function Documentation

§ instantiate()

bool Ingen::Server::LV2Block::instantiate	(	BufferFactory &	bufs,
		const LilvState *	state
	)

Instantiate self from LV2 plugin descriptor.

Implemented as a seperate function (rather than in the constructor) to allow graceful error-catching of broken plugins.

Returns whether or not plugin was successfully instantiated. If return value is false, this object may not be used.

References Ingen::Server::BlockImpl::_ports, Ingen::Resource::add_property(), apply_state(), load_preset(), Ingen::Server::BlockImpl::parent_graph(), Ingen::Server::Driver::sample_rate(), and Ingen::Resource::type().

§ duplicate()

BlockImpl * Ingen::Server::LV2Block::duplicate	(	Engine &	engine,
		const Raul::Symbol &	symbol,
		GraphImpl *	parent
	)

virtual

Duplicate this Node.

Reimplemented from Ingen::Server::BlockImpl.

References LV2Block(), Ingen::Resource::properties(), and Ingen::Server::Driver::sample_rate().

§ prepare_poly()

bool Ingen::Server::LV2Block::prepare_poly	(	BufferFactory &	bufs,
		uint32_t	poly
	)

virtual

Prepare for a new (external) polyphony value.

Preprocessor thread, poly is actually applied by apply_poly.

Returns: true on success.

Reimplemented from Ingen::Server::BlockImpl.

References Ingen::Server::BlockImpl::prepare_poly(), and Ingen::Server::Driver::sample_rate().

§ apply_poly()

bool Ingen::Server::LV2Block::apply_poly	(	RunContext &	context,
		Raul::Maid &	maid,
		uint32_t	poly
	)

virtual

Apply a new (external) polyphony value.

Parameters

context	Process context (process thread only).
poly	Must be <= the most recent value passed to prepare_poly.
maid	Any objects no longer needed will be pushed to this

Reimplemented from Ingen::Server::BlockImpl.

References Ingen::Server::BlockImpl::apply_poly().

§ activate()

void Ingen::Server::LV2Block::activate ( BufferFactory & bufs )

virtual

Activate this Block.

This function must be called in a non-realtime thread before it is inserted in to a graph. Any non-realtime actions that need to be done before the Block is ready for use should be done here.

Reimplemented from Ingen::Server::BlockImpl.

References Ingen::Server::BlockImpl::activate().
