Ingen::Server::RunContext Class Reference

Graph execution context. More...

#include <RunContext.hpp>

Collaboration diagram for Ingen::Server::RunContext:

Public Member Functions
	RunContext (Engine &engine, unsigned id, bool threaded)
	Create a new run context. More...
	RunContext (const RunContext &parent)
	Create a sub-context of parent. More...
bool	must_notify (const PortImpl *port) const
	Return true iff the given port should broadcast its value. More...
bool	notify (LV2_URID key=0, FrameTime time=0, PortImpl *port=0, uint32_t size=0, LV2_URID type=0, const void *body=NULL)
	Send a notification from this run context. More...
void	emit_notifications (FrameTime end)
	Emit pending notifications in some other non-realtime thread. More...
bool	pending_notifications () const
	Return true iff any notifications are pending. More...
uint64_t	duration () const
	Return the duration of this cycle in microseconds. More...
void	locate (FrameTime s, SampleCount nframes)
void	slice (SampleCount offset, SampleCount nframes)
void	set_task (Task *task)
void	set_priority (int priority)
void	set_rate (SampleCount rate)
Engine &	engine () const
Task *	task () const
unsigned	id () const
FrameTime	start () const
FrameTime	time () const
FrameTime	end () const
SampleCount	offset () const
SampleCount	nframes () const
SampleCount	rate () const
bool	realtime () const

Protected Member Functions
const RunContext &	operator= (const RunContext &copy)=delete
void	run ()

Protected Attributes
Engine &	_engine
	Engine we're running in.
Raul::RingBuffer *	_event_sink
	Port updates from process context.
Task *	_task
	Currently executing task.
std::thread *	_thread
	Thread (NULL for main run context)
unsigned	_id
	Context ID.
FrameTime	_start
	Start frame of this cycle, timeline relative.
FrameTime	_end
	End frame of this cycle, timeline relative.
SampleCount	_offset
	Offset into data buffers.
SampleCount	_nframes
	Number of frames past offset to process.
SampleCount	_rate
	Sample rate in Hz.
bool	_realtime
	True iff context is hard realtime.
bool	_copy
	True iff this is a copy (shared event_sink)

Detailed Description

Graph execution context.

This is used to pass whatever information a Node might need to process; such as the current time, a sink for generated events, etc.

Note the logical distinction between nframes (jack relative) and start/end (timeline relative). If transport speed != 1.0, then end-start != nframes (though currently this is never the case, it may be if ingen incorporates tempo and varispeed).

Constructor & Destructor Documentation

RunContext() [1/2]

Ingen::Server::RunContext::RunContext	(	Engine &	engine,
		unsigned	id,
		bool	threaded
	)

Create a new run context.

Parameters

threaded

If true, then this context is a worker which will launch a thread and execute tasks as they become available.

RunContext() [2/2]

Ingen::Server::RunContext::RunContext

(

const RunContext &

parent

)

Create a sub-context of parent.

This is used to subdivide process cycles, the sub-context is lightweight and only serves to pass different time attributes.

References _copy, and _event_sink.

Member Function Documentation

must_notify()

bool Ingen::Server::RunContext::must_notify

(

const PortImpl *

port

)

const

Return true iff the given port should broadcast its value.

Whether or not broadcasting is actually done is a per-client property, this is for use in the audio thread to quickly determine if the necessary calculations need to be done at all.

References _engine, Ingen::Server::PortImpl::is_monitored(), and Ingen::Server::Broadcaster::must_broadcast().

Referenced by Ingen::Server::PortImpl::monitor().

notify()

bool Ingen::Server::RunContext::notify	(	LV2_URID	key = 0,
		FrameTime	time = 0,
		PortImpl *	port = 0,
		uint32_t	size = 0,
		LV2_URID	type = 0,
		const void *	body = NULL
	)

Send a notification from this run context.

Returns

false on failure (ring is full)

References _engine, and _event_sink.

Referenced by Ingen::Server::PortImpl::monitor().

emit_notifications()

void Ingen::Server::RunContext::emit_notifications

(

FrameTime

end

)

Emit pending notifications in some other non-realtime thread.

References _engine, _event_sink, and _thread.

pending_notifications()

bool Ingen::Server::RunContext::pending_notifications ( ) const

inline

Return true iff any notifications are pending.

References _event_sink.

duration()

uint64_t Ingen::Server::RunContext::duration ( ) const

inline

Return the duration of this cycle in microseconds.

This is the cycle length in frames (nframes) converted to microseconds, that is, the amount of real time that this cycle's audio represents. Note that this is unrelated to the amount of time available to execute a cycle (other than the fact that it must be processed in significantly less time to avoid a dropout when running in real time).

References _end, _engine, _id, _nframes, _offset, _rate, _realtime, _start, and _task.

Referenced by Ingen::Server::Engine::run().

---

The documentation for this class was generated from the following files:

• RunContext.hpp
• RunContext.cpp
