An object on the audio graph (a Graph, Block, or Port). More...

#include <NodeImpl.hpp>

Inheritance diagram for Ingen::Server::NodeImpl:

Collaboration diagram for Ingen::Server::NodeImpl:

Public Member Functions
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

virtual GraphImpl *	parent_graph () const
	The Graph this object is a child of. More...

const Raul::Path &	path () const

virtual bool	prepare_poly (BufferFactory &bufs, uint32_t poly)=0
	Prepare for a new (external) polyphony value. More...

virtual bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)=0
	Apply a new (external) polyphony value. More...

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual uint32_t	num_ports () const

virtual Node *	port (uint32_t index) const

virtual const Resource *	plugin () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

virtual GraphType	graph_type () const =0

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Protected Member Functions
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Protected Attributes
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Additional Inherited Members
Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Detailed Description

An object on the audio graph (a Graph, Block, or Port).

Each of these is a Raul::Deletable and so can be deleted in a realtime safe way from anywhere, and they all have a map of variable for clients to store arbitrary values in (which the engine puts no significance to whatsoever).

Member Function Documentation

§ get_property()

const Atom & Ingen::Server::NodeImpl::get_property ( const Raul::URI & uri ) const

virtual

Get a single property value.

This is only useful for properties with a single value. If the requested property has several values, the first will be returned.

Reimplemented from Ingen::Resource.

References Ingen::Resource::properties().

§ parent_graph()

GraphImpl * Ingen::Server::NodeImpl::parent_graph ( ) const

virtual

The Graph this object is a child of.

Reimplemented in Ingen::Server::BlockImpl.

§ prepare_poly()

virtual bool Ingen::Server::NodeImpl::prepare_poly	(	BufferFactory &	bufs,
		uint32_t	poly
	)

pure virtual

Prepare for a new (external) polyphony value.

Preprocessor thread, poly is actually applied by apply_poly.

Returns: true on success.

Implemented in Ingen::Server::BlockImpl, Ingen::Server::PortImpl, Ingen::Server::DuplexPort, Ingen::Server::LV2Block, and Ingen::Server::Internals::NoteNode.

§ apply_poly()

virtual bool Ingen::Server::NodeImpl::apply_poly	(	RunContext &	context,
		Raul::Maid &	maid,
		uint32_t	poly
	)

pure virtual

Apply a new (external) polyphony value.

Parameters

context	Process context (process thread only).
poly	Must be <= the most recent value passed to prepare_poly.
maid	Any objects no longer needed will be pushed to this

Implemented in Ingen::Server::BlockImpl, Ingen::Server::PortImpl, Ingen::Server::DuplexPort, Ingen::Server::InputPort, Ingen::Server::LV2Block, and Ingen::Server::Internals::NoteNode.

The documentation for this class was generated from the following files:

NodeImpl.hpp
NodeImpl.cpp
