A group of blocks in a graph, possibly polyphonic. More...

#include <GraphImpl.hpp>

Inheritance diagram for Ingen::Server::GraphImpl:

Collaboration diagram for Ingen::Server::GraphImpl:

Public Types
typedef boost::intrusive::slist< BlockImpl, boost::intrusive::constant_time_size< true > >	Blocks

typedef boost::intrusive::slist< DuplexPort, boost::intrusive::constant_time_size< true > >	Ports

Public Types inherited from Ingen::Server::BlockImpl
enum	Mark { UNVISITED, VISITING, VISITED }
	Mark used during graph compilation.

Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Public Member Functions
	GraphImpl (Engine &engine, const Raul::Symbol &symbol, uint32_t poly, GraphImpl *parent, SampleRate srate, uint32_t local_poly)

virtual GraphType	graph_type () const

BlockImpl *	duplicate (Engine &engine, const Raul::Symbol &symbol, GraphImpl *parent)
	Duplicate this Node. More...

void	activate (BufferFactory &bufs)
	Activate this Block. More...

void	deactivate ()
	Deactivate this Block. More...

void	pre_process (RunContext &context)
	Do whatever needs doing in the process thread before process() is called.

void	process (RunContext &context)
	Run block for an entire process cycle (calls run()). More...

void	run (RunContext &context)
	Run block for a portion of process cycle (called from process()). More...

void	set_buffer_size (RunContext &context, BufferFactory &bufs, LV2_URID type, uint32_t size)

bool	prepare_internal_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (internal) polyphony value. More...

bool	apply_internal_poly (RunContext &context, BufferFactory &bufs, Raul::Maid &maid, uint32_t poly)
	Apply a new (internal) polyphony value. More...

void	add_block (BlockImpl &block)
	Add a block to this graph. More...

void	remove_block (BlockImpl &block)
	Remove a block from this graph. More...

Blocks &	blocks ()

const Blocks &	blocks () const

uint32_t	num_ports_non_rt () const

void	add_input (DuplexPort &port)

void	add_output (DuplexPort &port)

void	remove_port (DuplexPort &port)
	Remove port from ports list used in pre-processing thread. More...

void	clear_ports ()
	Remove all ports from ports list used in pre-processing thread. More...

void	add_arc (SPtr< ArcImpl > arc)
	Add an arc to this graph. More...

SPtr< ArcImpl >	remove_arc (const PortImpl tail, const PortImpl head)
	Remove an arc from this graph. More...

bool	has_arc (const PortImpl tail, const PortImpl head) const

CompiledGraph *	swap_compiled_graph (CompiledGraph *cp) INGEN_WARN_UNUSED_RESULT
	Set a new compiled graph to run, and return the old one. More...

Raul::Array< PortImpl * > *	external_ports ()

void	external_ports (Raul::Array< PortImpl > pa)

Raul::Array< PortImpl * > *	build_ports_array ()

bool	enabled () const
	Whether to run this graph's DSP bits in the audio thread.

void	enable ()

void	disable (RunContext &context)

uint32_t	internal_poly () const

uint32_t	internal_poly_process () const

Engine &	engine ()

Public Member Functions inherited from Ingen::Server::BlockImpl
	BlockImpl (PluginImpl plugin, const Raul::Symbol &symbol, bool poly, GraphImpl parent, SampleRate rate)

bool	activated () const
	Return true iff this block is activated.

bool	enabled () const
	Return true iff this block is enabled (not bypassed). More...

void	set_enabled (bool e)
	Enable or disable (bypass) this block. More...

virtual LilvState *	load_preset (const Raul::URI &uri)
	Load a preset from the world for this block. More...

virtual void	apply_state (Worker worker, const LilvState state)
	Restore `state`. More...

virtual boost::optional< Resource >	save_preset (const Raul::URI &bundle, const Properties &props)
	Save current state as preset. More...

virtual void	learn ()
	Learn the next incoming MIDI event (for internals)

virtual void	post_process (RunContext &context)
	Do whatever needs doing in the process thread after process() is called.

virtual void	set_port_buffer (uint32_t voice, uint32_t port_num, BufferRef buf, SampleCount offset)
	Set the buffer of a port to a given buffer (e.g. More...

virtual Node *	port (uint32_t index) const

virtual PortImpl *	port_impl (uint32_t index) const

virtual PortImpl *	port_by_symbol (const char *symbol)
	Get a port by symbol. More...

std::set< BlockImpl * > &	providers ()
	Blocks that are connected to this Block's inputs. More...

std::set< BlockImpl * > &	dependants ()
	Blocks that are connected to this Block's outputs. More...

virtual void	set_polyphonic (bool p)
	Flag block as polyphonic. More...

virtual bool	prepare_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (external) polyphony value. More...

virtual bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new (external) polyphony value. More...

virtual const Resource *	plugin () const
	Information about the Plugin this Block is an instance of. More...

virtual const PluginImpl *	plugin_impl () const
	Information about the Plugin this Block is an instance of. More...

virtual void	plugin (PluginImpl *pi)

GraphImpl *	parent_graph () const
	The Graph this Block belongs to. More...

uint32_t	num_ports () const

virtual uint32_t	polyphony () const

Mark	get_mark () const

void	set_mark (Mark m)

Public Member Functions inherited from Ingen::Server::NodeImpl
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

const Raul::Path &	path () const

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Additional Inherited Members
Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Protected Member Functions inherited from Ingen::Server::BlockImpl
PortImpl *	nth_port_by_type (uint32_t n, bool input, PortType type)

Protected Member Functions inherited from Ingen::Server::NodeImpl
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Protected Attributes inherited from Ingen::Server::BlockImpl
PluginImpl *	_plugin

Raul::Array< PortImpl * > *	_ports
	Access in audio thread only.

uint32_t	_polyphony

std::set< BlockImpl * >	_providers
	Blocks connected to this one's input ports.

std::set< BlockImpl * >	_dependants
	Blocks this one's output ports are connected to.

Mark	_mark
	Mark for graph compilation algorithm.

bool	_polyphonic

bool	_activated

bool	_enabled

Protected Attributes inherited from Ingen::Server::NodeImpl
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Detailed Description

A group of blocks in a graph, possibly polyphonic.

Note that this is also a Block, just one which contains Blocks. Therefore infinite subgraphing is possible, of polyphonic graphs of polyphonic blocks etc. etc.

Member Function Documentation

§ duplicate()

BlockImpl * Ingen::Server::GraphImpl::duplicate	(	Engine &	engine,
		const Raul::Symbol &	symbol,
		GraphImpl *	parent
	)

virtual

Duplicate this Node.

Reimplemented from Ingen::Server::BlockImpl.

References Ingen::Server::BlockImpl::_ports, Ingen::Server::BlockImpl::activate(), add_arc(), add_block(), Ingen::Server::BlockImpl::duplicate(), Ingen::Server::Driver::sample_rate(), and Ingen::Resource::set_properties().

§ activate()

void Ingen::Server::GraphImpl::activate ( BufferFactory & bufs )

virtual

Activate this Block.

This function must be called in a non-realtime thread before it is inserted in to a graph. Any non-realtime actions that need to be done before the Block is ready for use should be done here.

Reimplemented from Ingen::Server::BlockImpl.

Referenced by Ingen::Server::Engine::activate().

§ deactivate()

void Ingen::Server::GraphImpl::deactivate ( )

virtual

Deactivate this Block.

This function must be called in a non-realtime thread after the block has been removed from its graph (i.e. processing is finished).

Reimplemented from Ingen::Server::BlockImpl.

§ process()

void Ingen::Server::GraphImpl::process ( RunContext & context )

virtual

Run block for an entire process cycle (calls run()).

Reimplemented from Ingen::Server::BlockImpl.

§ run()

void Ingen::Server::GraphImpl::run ( RunContext & context )

virtual

Run block for a portion of process cycle (called from process()).

Implements Ingen::Server::BlockImpl.

§ prepare_internal_poly()

bool Ingen::Server::GraphImpl::prepare_internal_poly	(	BufferFactory &	bufs,
		uint32_t	poly
	)

Prepare for a new (internal) polyphony value.

Pre-process thread, poly is actually applied by apply_internal_poly.

Returns: true on success.

§ apply_internal_poly()

bool Ingen::Server::GraphImpl::apply_internal_poly	(	RunContext &	context,
		BufferFactory &	bufs,
		Raul::Maid &	maid,
		uint32_t	poly
	)

Apply a new (internal) polyphony value.

Audio thread.

Parameters

context	Process context
bufs	New set of buffers
poly	Must be < the most recent value passed to prepare_internal_poly.
maid	Any objects no longer needed will be pushed to this

§ add_block()

void Ingen::Server::GraphImpl::add_block ( BlockImpl & block )

Add a block to this graph.

Pre-process thread only.

Referenced by duplicate().

§ remove_block()

void Ingen::Server::GraphImpl::remove_block ( BlockImpl & block )

Remove a block from this graph.

Pre-process thread only.

§ remove_port()

void Ingen::Server::GraphImpl::remove_port ( DuplexPort & port )

Remove port from ports list used in pre-processing thread.

Port is not removed from ports array for process thread (which could be simultaneously running).

Pre-processing thread or situations that won't cause races with it only.

§ clear_ports()

void Ingen::Server::GraphImpl::clear_ports ( )

Remove all ports from ports list used in pre-processing thread.

Ports are not removed from ports array for process thread (which could be simultaneously running). Returned is a (inputs, outputs) pair.

Pre-processing thread or situations that won't cause races with it only.

§ add_arc()

void Ingen::Server::GraphImpl::add_arc ( SPtr< ArcImpl > arc )

Add an arc to this graph.

Pre-processing thread only.

Referenced by duplicate().

§ remove_arc()

SPtr< ArcImpl > Ingen::Server::GraphImpl::remove_arc	(	const PortImpl *	tail,
		const PortImpl *	head
	)

Remove an arc from this graph.

Pre-processing thread only.

§ swap_compiled_graph()

CompiledGraph * Ingen::Server::GraphImpl::swap_compiled_graph ( CompiledGraph * cp )

Set a new compiled graph to run, and return the old one.

The documentation for this class was generated from the following files:

GraphImpl.hpp
GraphImpl.cpp

Public Types

Public Member Functions

Additional Inherited Members

Detailed Description

Member Function Documentation

§ duplicate()

§ activate()

§ deactivate()

§ process()

§ run()

§ prepare_internal_poly()

§ apply_internal_poly()

§ add_block()

§ remove_block()

§ remove_port()

§ clear_ports()

§ add_arc()

§ remove_arc()

§ swap_compiled_graph()
