An object on the audio graph. More...
#include <Node.hpp>
Inheritance diagram for Ingen::Node:
Collaboration diagram for Ingen::Node:
Public Types | |
| enum | GraphType { GRAPH, BLOCK, PORT } |
| typedef std::pair< const Node *, const Node * > | ArcsKey |
| typedef std::map< ArcsKey, SPtr< Arc > > | Arcs |
| Public Types inherited from Ingen::Resource | |
| enum | Graph { DEFAULT, EXTERNAL, INTERNAL } |
Public Member Functions | |
| Arcs & | arcs () |
| const Arcs & | arcs () const |
| virtual uint32_t | num_ports () const |
| virtual Node * | port (uint32_t index) const |
| virtual const Resource * | plugin () const |
| virtual LilvInstance * | instance () |
| virtual bool | save_state (const std::string &dir) const |
| virtual GraphType | graph_type () const =0 |
| virtual const Raul::Path & | path () const =0 |
| virtual const Raul::Symbol & | symbol () const =0 |
| virtual Node * | graph_parent () const =0 |
| Raul::URI | base_uri () const |
| Public Member Functions inherited from Ingen::Resource | |
| Resource (const URIs &uris, const Raul::URI &uri) | |
| Resource & | operator= (const Resource &rhs) |
| virtual const Atom & | get_property (const Raul::URI &uri) const |
| Get a single property value. More... | |
| virtual const Atom & | set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT) |
| Set (replace) a property value. More... | |
| virtual const Atom & | set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT) |
| Set (replace) a property value. More... | |
| virtual bool | add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT) |
| Add a property value. More... | |
| virtual void | remove_property (const Raul::URI &uri, const Atom &value) |
| Remove a property. More... | |
| virtual void | remove_property (const Raul::URI &uri, const URIs::Quark &value) |
| Remove a property. More... | |
| virtual bool | has_property (const Raul::URI &uri, const Atom &value) const |
| Return true iff a property is set with a specific value. More... | |
| virtual bool | has_property (const Raul::URI &uri, const URIs::Quark &value) const |
| Return true iff a property is set with a specific value. More... | |
| void | set_properties (const Properties &p) |
| Set (replace) several properties at once. More... | |
| void | add_properties (const Properties &p) |
| Add several properties at once. More... | |
| void | remove_properties (const Properties &p) |
| Remove several properties at once. More... | |
| virtual void | on_property (const Raul::URI &uri, const Atom &value) |
| Hook called whenever a property is added. More... | |
| virtual void | on_property_removed (const Raul::URI &uri, const Atom &value) |
| Hook called whenever a property value is removed. More... | |
| virtual void | set_uri (const Raul::URI &uri) |
| Properties | properties (Resource::Graph ctx) const |
| Get all the properties with a given context. More... | |
| const URIs & | uris () const |
| const Raul::URI & | uri () const |
| const Properties & | properties () const |
| Properties & | properties () |
Static Public Member Functions | |
| static Raul::URI | main_uri () |
| static bool | uri_is_path (const Raul::URI &uri) |
| static Raul::Path | uri_to_path (const Raul::URI &uri) |
| static Raul::URI | path_to_uri (const Raul::Path &path) |
| Static Public Member Functions inherited from Ingen::Resource | |
| static Raul::URI | graph_to_uri (Graph g) |
| static Graph | uri_to_graph (const char *uri) |
| static bool | type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output) |
| Get the ingen type from a set of Properties. More... | |
Protected Member Functions | |
| virtual void | set_path (const Raul::Path &p)=0 |
| Node (const URIs &uris, const Raul::Path &path) | |
| Protected Member Functions inherited from Ingen::Resource | |
| const Atom & | set_property (const Raul::URI &uri, const Atom &value) const |
Protected Attributes | |
| Arcs | _arcs |
| Graphs only. | |
| Protected Attributes inherited from Ingen::Resource | |
| const URIs & | _uris |
Friends | |
| class | Store |
Detailed Description
An object on the audio graph.
The key property of nodes is that all nodes have a path and a symbol, as well as a URI.
To avoid ugly inheritance issues and the need for excessive use of dynamic_cast, this class contains some members which are only applicable to certain types of node. There is a type tag which can be used to determine the type of any Node.
The documentation for this class was generated from the following file:
- Node.hpp
