A port (input or output) on a Block. More...

#include <PortImpl.hpp>

Inheritance diagram for Ingen::Server::PortImpl:

Collaboration diagram for Ingen::Server::PortImpl:

Classes
struct	SetState

struct	Voice

Public Member Functions
virtual GraphType	graph_type () const

BlockImpl *	parent_block () const
	A port's parent is always a block, so static cast should be safe.

Raul::Array< Voice > *	set_voices (RunContext &context, Raul::Array< Voice > *voices)
	Set the buffers array for this port. More...

virtual bool	prepare_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (external) polyphony value. More...

virtual bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new polyphony value. More...

const Atom &	value () const

void	set_value (const Atom &v)

const Atom &	minimum () const

const Atom &	maximum () const

void	set_minimum (const Atom &min)

void	set_maximum (const Atom &max)

BufferRef	buffer (uint32_t voice) const

BufferRef	prepared_buffer (uint32_t voice) const

void	update_set_state (RunContext &context, uint32_t voice)

void	set_voice_value (const RunContext &context, uint32_t voice, FrameTime time, Sample value)

void	set_control_value (const RunContext &context, FrameTime time, Sample value)

virtual void	set_is_driver_port (BufferFactory &bufs)
	Prepare this port to use an external driver-provided buffer. More...

bool	is_driver_port () const

virtual void	pre_process (RunContext &context)=0
	Called once per process cycle.

virtual void	pre_run (RunContext &context)

virtual void	post_process (RunContext &context)=0

virtual void	clear_buffers ()
	Empty buffer contents completely (ie silence)

virtual bool	get_buffers (BufferFactory &bufs, Raul::Array< Voice > *voices, uint32_t poly, bool real_time) const =0

void	setup_buffers (BufferFactory &bufs, uint32_t poly, bool real_time)

void	activate (BufferFactory &bufs)

void	deactivate ()

virtual void	inherit_neighbour (const PortImpl *port, Resource::Properties &remove, Resource::Properties &add)
	Inherit any properties from a connected neighbour. More...

virtual void	connect_buffers (SampleCount offset=0)

virtual void	recycle_buffers ()

virtual bool	is_input () const =0

virtual bool	is_output () const =0

uint32_t	index () const

bool	is_a (PortType type) const

bool	has_value () const

PortType	type () const

LV2_URID	buffer_type () const

bool	supports (const URIs::Quark &value_type) const

size_t	buffer_size () const

uint32_t	poly () const

uint32_t	prepared_poly () const

void	set_buffer_size (RunContext &context, BufferFactory &bufs, size_t size)

bool	is_monitored () const
	Return true iff this port is explicitly monitored. More...

void	enable_monitoring (bool monitored)
	Explicitly turn on monitoring for this port. More...

void	monitor (RunContext &context, bool send_now=false)
	Monitor port value and broadcast to clients periodically. More...

void	raise_set_by_user_flag ()

BufferFactory &	bufs () const

BufferRef	value_buffer (uint32_t voice)

virtual SampleCount	next_value_offset (SampleCount offset, SampleCount end) const
	Return offset of the first value change after `offset`. More...

virtual void	update_values (SampleCount offset, uint32_t voice)=0
	Update value buffer for `voice` to be current as of `offset`. More...

void	force_monitor_update ()

void	set_morphable (bool is_morph, bool is_auto_morph)

void	set_type (PortType port_type, LV2_URID buffer_type)

void	cache_properties ()

bool	is_morph () const

bool	is_auto_morph () const

bool	is_logarithmic () const

bool	is_sample_rate () const

bool	is_toggled () const

Public Member Functions inherited from Ingen::Server::NodeImpl
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

virtual GraphImpl *	parent_graph () const
	The Graph this object is a child of. More...

const Raul::Path &	path () const

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual uint32_t	num_ports () const

virtual Node *	port (uint32_t index) const

virtual const Resource *	plugin () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Protected Member Functions
	PortImpl (BufferFactory &bufs, BlockImpl *block, const Raul::Symbol &name, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size)

Protected Member Functions inherited from Ingen::Server::NodeImpl
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Protected Attributes
BufferFactory &	_bufs

uint32_t	_index

uint32_t	_poly

uint32_t	_buffer_size

uint32_t	_frames_since_monitor

float	_monitor_value

float	_peak

PortType	_type

LV2_URID	_buffer_type

Atom	_value

Atom	_min

Atom	_max

Raul::Array< Voice > *	_voices

Raul::Array< Voice > *	_prepared_voices

bool	_monitored

bool	_force_monitor_update

bool	_set_by_user

bool	_is_morph

bool	_is_auto_morph

bool	_is_logarithmic

bool	_is_sample_rate

bool	_is_toggled

bool	_is_driver_port

Protected Attributes inherited from Ingen::Server::NodeImpl
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Additional Inherited Members
Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Detailed Description

A port (input or output) on a Block.

Member Function Documentation

§ set_voices()

Raul::Array< PortImpl::Voice > * Ingen::Server::PortImpl::set_voices	(	RunContext &	context,
		Raul::Array< Voice > *	voices
	)

Set the buffers array for this port.

Audio thread. Returned value must be freed by caller. buffers must be poly() long

References Ingen::Server::PortImpl::SetState::state, Ingen::Server::PortImpl::SetState::time, and Ingen::Server::PortImpl::SetState::value.

§ prepare_poly()

bool Ingen::Server::PortImpl::prepare_poly	(	BufferFactory &	bufs,
		uint32_t	poly
	)

virtual

Prepare for a new (external) polyphony value.

Preprocessor thread, poly is actually applied by apply_poly.

Implements Ingen::Server::NodeImpl.

Reimplemented in Ingen::Server::DuplexPort.

Referenced by Ingen::Server::DuplexPort::prepare_poly().

§ apply_poly()

bool Ingen::Server::PortImpl::apply_poly	(	RunContext &	context,
		Raul::Maid &	maid,
		uint32_t	poly
	)

virtual

Apply a new polyphony value.

Audio thread. poly Must be < the most recent value passed to prepare_poly.

Implements Ingen::Server::NodeImpl.

Reimplemented in Ingen::Server::DuplexPort, and Ingen::Server::InputPort.

Referenced by Ingen::Server::DuplexPort::apply_poly().

§ set_is_driver_port()

void Ingen::Server::PortImpl::set_is_driver_port ( BufferFactory & bufs )

virtual

Prepare this port to use an external driver-provided buffer.

This will avoid allocating a buffer for the port, instead the driver buffer is used directly. This only makes sense for ports on the top-level graph, which are monophonic. Non-real-time, must be called before using the port, followed by a call to set_driver_buffer() in the processing thread.

Reimplemented in Ingen::Server::DuplexPort.

Referenced by Ingen::Server::DuplexPort::set_is_driver_port().

§ inherit_neighbour()

virtual void Ingen::Server::PortImpl::inherit_neighbour	(	const PortImpl *	port,
		Resource::Properties &	remove,
		Resource::Properties &	add
	)

inlinevirtual

Inherit any properties from a connected neighbour.

This is used for Graph ports, so e.g. a control input has the range of all the ports it is connected to.

Reimplemented in Ingen::Server::DuplexPort.

§ is_monitored()

bool Ingen::Server::PortImpl::is_monitored ( ) const

inline

Return true iff this port is explicitly monitored.

This is used for plugin UIs which require monitoring for particular ports, even if the Ingen client has not requested broadcasting in general (e.g. for canvas animation).

Referenced by Ingen::Server::RunContext::must_notify().
