A duplex Port (both an InputPort and an OutputPort on a Graph) More...

#include <DuplexPort.hpp>

Inheritance diagram for Ingen::Server::DuplexPort:

Collaboration diagram for Ingen::Server::DuplexPort:

Public Member Functions
	DuplexPort (BufferFactory &bufs, GraphImpl *parent, const Raul::Symbol &symbol, uint32_t index, bool polyphonic, PortType type, LV2_URID buf_type, size_t buf_size, const Atom &value, bool is_output)

DuplexPort *	duplicate (Engine &engine, const Raul::Symbol &symbol, GraphImpl *parent)

void	inherit_neighbour (const PortImpl *port, Resource::Properties &remove, Resource::Properties &add)
	Inherit any properties from a connected neighbour. More...

void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

uint32_t	max_tail_poly (RunContext &context) const
	Return the maximum polyphony of an output connected to this input. More...

bool	prepare_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (external) polyphony value. More...

bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new polyphony value. More...

bool	get_buffers (BufferFactory &bufs, Raul::Array< Voice > *voices, uint32_t poly, bool real_time) const

virtual void	set_is_driver_port (BufferFactory &bufs)
	Prepare this port to use an external driver-provided buffer. More...

void	set_driver_buffer (void *buf, uint32_t capacity)
	Set the external driver-provided buffer. More...

void	pre_process (RunContext &context)
	Called once per process cycle.

void	post_process (RunContext &context)

SampleCount	next_value_offset (SampleCount offset, SampleCount end) const
	Return offset of the first value change after `offset`. More...

void	update_values (SampleCount offset, uint32_t voice)
	Update value buffer for `voice` to be current as of `offset`. More...

bool	is_input () const

bool	is_output () const

Public Member Functions inherited from Ingen::Server::InputPort
	InputPort (BufferFactory &bufs, BlockImpl *parent, const Raul::Symbol &symbol, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size=0)

bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new polyphony value. More...

void	add_arc (RunContext &context, ArcImpl *c)
	Add an arc. More...

ArcImpl *	remove_arc (RunContext &context, const OutputPort *tail)
	Remove an arc. More...

bool	get_buffers (BufferFactory &bufs, Raul::Array< Voice > *voices, uint32_t poly, bool real_time) const
	Set `voices` as the buffers to be used for this port. More...

void	pre_process (RunContext &context)
	Set up buffer pointers. More...

void	pre_run (RunContext &context)
	Prepare buffer for access, mixing if necessary. More...

void	post_process (RunContext &context)
	Prepare buffer for next process cycle. More...

SampleCount	next_value_offset (SampleCount offset, SampleCount end) const
	Return offset of the first value change after `offset`. More...

void	update_values (SampleCount offset, uint32_t voice)
	Update value buffer for `voice` to be current as of `offset`. More...

size_t	num_arcs () const
	Pre-process thread.

void	increment_num_arcs ()

void	decrement_num_arcs ()

bool	is_input () const

bool	is_output () const

bool	direct_connect () const

Public Member Functions inherited from Ingen::Server::PortImpl
virtual GraphType	graph_type () const

BlockImpl *	parent_block () const
	A port's parent is always a block, so static cast should be safe.

Raul::Array< Voice > *	set_voices (RunContext &context, Raul::Array< Voice > *voices)
	Set the buffers array for this port. More...

const Atom &	value () const

void	set_value (const Atom &v)

const Atom &	minimum () const

const Atom &	maximum () const

void	set_minimum (const Atom &min)

void	set_maximum (const Atom &max)

BufferRef	buffer (uint32_t voice) const

BufferRef	prepared_buffer (uint32_t voice) const

void	update_set_state (RunContext &context, uint32_t voice)

void	set_voice_value (const RunContext &context, uint32_t voice, FrameTime time, Sample value)

void	set_control_value (const RunContext &context, FrameTime time, Sample value)

bool	is_driver_port () const

virtual void	clear_buffers ()
	Empty buffer contents completely (ie silence)

void	setup_buffers (BufferFactory &bufs, uint32_t poly, bool real_time)

void	activate (BufferFactory &bufs)

void	deactivate ()

virtual void	connect_buffers (SampleCount offset=0)

virtual void	recycle_buffers ()

uint32_t	index () const

bool	is_a (PortType type) const

bool	has_value () const

PortType	type () const

LV2_URID	buffer_type () const

bool	supports (const URIs::Quark &value_type) const

size_t	buffer_size () const

uint32_t	poly () const

uint32_t	prepared_poly () const

void	set_buffer_size (RunContext &context, BufferFactory &bufs, size_t size)

bool	is_monitored () const
	Return true iff this port is explicitly monitored. More...

void	enable_monitoring (bool monitored)
	Explicitly turn on monitoring for this port. More...

void	monitor (RunContext &context, bool send_now=false)
	Monitor port value and broadcast to clients periodically. More...

void	raise_set_by_user_flag ()

BufferFactory &	bufs () const

BufferRef	value_buffer (uint32_t voice)

void	force_monitor_update ()

void	set_morphable (bool is_morph, bool is_auto_morph)

void	set_type (PortType port_type, LV2_URID buffer_type)

void	cache_properties ()

bool	is_morph () const

bool	is_auto_morph () const

bool	is_logarithmic () const

bool	is_sample_rate () const

bool	is_toggled () const

Public Member Functions inherited from Ingen::Server::NodeImpl
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

virtual GraphImpl *	parent_graph () const
	The Graph this object is a child of. More...

const Raul::Path &	path () const

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual uint32_t	num_ports () const

virtual Node *	port (uint32_t index) const

virtual const Resource *	plugin () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Public Member Functions inherited from Ingen::Server::OutputPort
	OutputPort (BufferFactory &bufs, BlockImpl *parent, const Raul::Symbol &symbol, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size=0)

bool	get_buffers (BufferFactory &bufs, Raul::Array< Voice > *voices, uint32_t poly, bool real_time) const

void	pre_process (RunContext &context)
	Called once per process cycle.

void	post_process (RunContext &context)

SampleCount	next_value_offset (SampleCount offset, SampleCount end) const
	Return offset of the first value change after `offset`. More...

void	update_values (SampleCount offset, uint32_t voice)
	Update value buffer for `voice` to be current as of `offset`. More...

bool	is_input () const

bool	is_output () const

Protected Attributes
bool	_is_output

Protected Attributes inherited from Ingen::Server::InputPort
size_t	_num_arcs
	Pre-process thread.

Arcs	_arcs
	Audio thread.

Protected Attributes inherited from Ingen::Server::PortImpl
BufferFactory &	_bufs

uint32_t	_index

uint32_t	_poly

uint32_t	_buffer_size

uint32_t	_frames_since_monitor

float	_monitor_value

float	_peak

PortType	_type

LV2_URID	_buffer_type

Atom	_value

Atom	_min

Atom	_max

Raul::Array< Voice > *	_voices

Raul::Array< Voice > *	_prepared_voices

bool	_monitored

bool	_force_monitor_update

bool	_set_by_user

bool	_is_morph

bool	_is_auto_morph

bool	_is_logarithmic

bool	_is_sample_rate

bool	_is_toggled

bool	_is_driver_port

Protected Attributes inherited from Ingen::Server::NodeImpl
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Additional Inherited Members
Public Types inherited from Ingen::Server::InputPort
typedef boost::intrusive::slist< ArcImpl, boost::intrusive::constant_time_size< false > >	Arcs

Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Protected Member Functions inherited from Ingen::Server::PortImpl
	PortImpl (BufferFactory &bufs, BlockImpl *block, const Raul::Symbol &name, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size)

Protected Member Functions inherited from Ingen::Server::NodeImpl
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Detailed Description

A duplex Port (both an InputPort and an OutputPort on a Graph)

This is used for Graph ports, since they need to appear as both an input and an output port based on context. There are no actual duplex ports in Ingen, a Port is either an Input or Output. This class only exists to allow Graph outputs to appear as inputs from within that Graph, and vice versa.

Member Function Documentation

§ inherit_neighbour()

void Ingen::Server::DuplexPort::inherit_neighbour	(	const PortImpl *	port,
		Resource::Properties &	remove,
		Resource::Properties &	add
	)

virtual

Inherit any properties from a connected neighbour.

This is used for Graph ports, so e.g. a control input has the range of all the ports it is connected to.

Reimplemented from Ingen::Server::PortImpl.

References Ingen::Resource::properties().

§ on_property()

void Ingen::Server::DuplexPort::on_property	(	const Raul::URI &	uri,
		const Atom &	value
	)

virtual

Hook called whenever a property is added.

This can be used by derived classes to implement special behaviour for particular properties (e.g. ingen:value for ports).

Reimplemented from Ingen::Resource.

References Ingen::Server::InputPort::get_buffers().

§ max_tail_poly()

uint32_t Ingen::Server::DuplexPort::max_tail_poly ( RunContext & context ) const

virtual

Return the maximum polyphony of an output connected to this input.

Reimplemented from Ingen::Server::InputPort.

§ prepare_poly()

bool Ingen::Server::DuplexPort::prepare_poly	(	BufferFactory &	bufs,
		uint32_t	poly
	)

virtual

Prepare for a new (external) polyphony value.

Preprocessor thread, poly is actually applied by apply_poly.

Reimplemented from Ingen::Server::PortImpl.

References Ingen::Server::PortImpl::prepare_poly().

§ apply_poly()

bool Ingen::Server::DuplexPort::apply_poly	(	RunContext &	context,
		Raul::Maid &	maid,
		uint32_t	poly
	)

virtual

Apply a new polyphony value.

Audio thread. poly Must be < the most recent value passed to prepare_poly.

Reimplemented from Ingen::Server::PortImpl.

References Ingen::Server::PortImpl::apply_poly().

§ set_is_driver_port()

void Ingen::Server::DuplexPort::set_is_driver_port ( BufferFactory & bufs )

virtual

Prepare this port to use an external driver-provided buffer.

This will avoid allocating a buffer for the port, instead the driver buffer is used directly. This only makes sense for ports on the top-level graph, which are monophonic. Non-real-time, must be called before using the port, followed by a call to set_driver_buffer() in the processing thread.

Reimplemented from Ingen::Server::PortImpl.

References Ingen::Server::PortImpl::set_is_driver_port().

Referenced by Ingen::Server::JackDriver::create_port().
