An input port on a Block or Graph. More...

#include <InputPort.hpp>

Inheritance diagram for Ingen::Server::InputPort:

Collaboration diagram for Ingen::Server::InputPort:

Public Types
typedef boost::intrusive::slist< ArcImpl, boost::intrusive::constant_time_size< false > >	Arcs

Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Public Member Functions
	InputPort (BufferFactory &bufs, BlockImpl *parent, const Raul::Symbol &symbol, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size=0)

virtual uint32_t	max_tail_poly (RunContext &context) const
	Return the maximum polyphony of an output connected to this input. More...

bool	apply_poly (RunContext &context, Raul::Maid &maid, uint32_t poly)
	Apply a new polyphony value. More...

void	add_arc (RunContext &context, ArcImpl *c)
	Add an arc. More...

ArcImpl *	remove_arc (RunContext &context, const OutputPort *tail)
	Remove an arc. More...

bool	get_buffers (BufferFactory &bufs, Raul::Array< Voice > *voices, uint32_t poly, bool real_time) const
	Set `voices` as the buffers to be used for this port. More...

void	pre_process (RunContext &context)
	Set up buffer pointers. More...

void	pre_run (RunContext &context)
	Prepare buffer for access, mixing if necessary. More...

void	post_process (RunContext &context)
	Prepare buffer for next process cycle. More...

SampleCount	next_value_offset (SampleCount offset, SampleCount end) const
	Return offset of the first value change after `offset`. More...

void	update_values (SampleCount offset, uint32_t voice)
	Update value buffer for `voice` to be current as of `offset`. More...

size_t	num_arcs () const
	Pre-process thread.

void	increment_num_arcs ()

void	decrement_num_arcs ()

bool	is_input () const

bool	is_output () const

bool	direct_connect () const

Public Member Functions inherited from Ingen::Server::PortImpl
virtual GraphType	graph_type () const

BlockImpl *	parent_block () const
	A port's parent is always a block, so static cast should be safe.

Raul::Array< Voice > *	set_voices (RunContext &context, Raul::Array< Voice > *voices)
	Set the buffers array for this port. More...

virtual bool	prepare_poly (BufferFactory &bufs, uint32_t poly)
	Prepare for a new (external) polyphony value. More...

const Atom &	value () const

void	set_value (const Atom &v)

const Atom &	minimum () const

const Atom &	maximum () const

void	set_minimum (const Atom &min)

void	set_maximum (const Atom &max)

BufferRef	buffer (uint32_t voice) const

BufferRef	prepared_buffer (uint32_t voice) const

void	update_set_state (RunContext &context, uint32_t voice)

void	set_voice_value (const RunContext &context, uint32_t voice, FrameTime time, Sample value)

void	set_control_value (const RunContext &context, FrameTime time, Sample value)

virtual void	set_is_driver_port (BufferFactory &bufs)
	Prepare this port to use an external driver-provided buffer. More...

bool	is_driver_port () const

virtual void	clear_buffers ()
	Empty buffer contents completely (ie silence)

void	setup_buffers (BufferFactory &bufs, uint32_t poly, bool real_time)

void	activate (BufferFactory &bufs)

void	deactivate ()

virtual void	inherit_neighbour (const PortImpl *port, Resource::Properties &remove, Resource::Properties &add)
	Inherit any properties from a connected neighbour. More...

virtual void	connect_buffers (SampleCount offset=0)

virtual void	recycle_buffers ()

uint32_t	index () const

bool	is_a (PortType type) const

bool	has_value () const

PortType	type () const

LV2_URID	buffer_type () const

bool	supports (const URIs::Quark &value_type) const

size_t	buffer_size () const

uint32_t	poly () const

uint32_t	prepared_poly () const

void	set_buffer_size (RunContext &context, BufferFactory &bufs, size_t size)

bool	is_monitored () const
	Return true iff this port is explicitly monitored. More...

void	enable_monitoring (bool monitored)
	Explicitly turn on monitoring for this port. More...

void	monitor (RunContext &context, bool send_now=false)
	Monitor port value and broadcast to clients periodically. More...

void	raise_set_by_user_flag ()

BufferFactory &	bufs () const

BufferRef	value_buffer (uint32_t voice)

void	force_monitor_update ()

void	set_morphable (bool is_morph, bool is_auto_morph)

void	set_type (PortType port_type, LV2_URID buffer_type)

void	cache_properties ()

bool	is_morph () const

bool	is_auto_morph () const

bool	is_logarithmic () const

bool	is_sample_rate () const

bool	is_toggled () const

Public Member Functions inherited from Ingen::Server::NodeImpl
const Raul::Symbol &	symbol () const

Node *	graph_parent () const

NodeImpl *	parent () const

virtual void	set_path (const Raul::Path &new_path)
	Rename.

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

virtual GraphImpl *	parent_graph () const
	The Graph this object is a child of. More...

const Raul::Path &	path () const

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual uint32_t	num_ports () const

virtual Node *	port (uint32_t index) const

virtual const Resource *	plugin () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

virtual void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Protected Attributes
size_t	_num_arcs
	Pre-process thread.

Arcs	_arcs
	Audio thread.

Protected Attributes inherited from Ingen::Server::PortImpl
BufferFactory &	_bufs

uint32_t	_index

uint32_t	_poly

uint32_t	_buffer_size

uint32_t	_frames_since_monitor

float	_monitor_value

float	_peak

PortType	_type

LV2_URID	_buffer_type

Atom	_value

Atom	_min

Atom	_max

Raul::Array< Voice > *	_voices

Raul::Array< Voice > *	_prepared_voices

bool	_monitored

bool	_force_monitor_update

bool	_set_by_user

bool	_is_morph

bool	_is_auto_morph

bool	_is_logarithmic

bool	_is_sample_rate

bool	_is_toggled

bool	_is_driver_port

Protected Attributes inherited from Ingen::Server::NodeImpl
NodeImpl *	_parent

Raul::Path	_path

Raul::Symbol	_symbol

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Additional Inherited Members
Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Protected Member Functions inherited from Ingen::Server::PortImpl
	PortImpl (BufferFactory &bufs, BlockImpl *block, const Raul::Symbol &name, uint32_t index, uint32_t poly, PortType type, LV2_URID buffer_type, const Atom &value, size_t buffer_size)

Protected Member Functions inherited from Ingen::Server::NodeImpl
	NodeImpl (const Ingen::URIs &uris, NodeImpl *parent, const Raul::Symbol &symbol)

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Detailed Description

An input port on a Block or Graph.

All ports have a Buffer, but the actual contents (data) of that buffer may be set directly to the incoming arc's buffer if there's only one inbound arc, to eliminate the need to copy/mix.

If a port has multiple arcs, they will be mixed down into the local buffer and it will be used.
