Ingen::Server::Event Class Reference

An event (command) to perform some action on Ingen. More...

#include <Event.hpp>

Inheritance diagram for Ingen::Server::Event:

Collaboration diagram for Ingen::Server::Event:

Public Types
enum	Mode {   NORMAL,   UNDO,   REDO }
	Event mode to distinguish normal events from undo events. More...
enum	Execution {   NORMAL,   BLOCK,   UNBLOCK }
	Execution mode for events that block and unblock preprocessing. More...

Public Member Functions
virtual bool	pre_process (PreProcessContext &ctx)=0
	Pre-process event before execution (non-realtime). More...
virtual void	execute (RunContext &context)=0
	Execute this event in the audio thread (realtime). More...
virtual void	post_process ()=0
	Post-process event after execution (non-realtime). More...
virtual void	undo (Interface &target)
	Write the inverse of this event to sink. More...
bool	is_prepared () const
	Return true iff this event has been pre-processed. More...
SampleCount	time () const
	Return the time stamp of this event. More...
void	set_time (SampleCount time)
	Set the time stamp of this event. More...
Event *	next () const
	Get the next event to be processed after this one. More...
void	next (Event *ev)
	Set the next event to be processed after this one. More...
Status	status () const
	Return the status (success or error code) of this event. More...
virtual Execution	get_execution () const
	Return the blocking behaviour of this event (after pre_process())
Mode	get_mode () const
	Return undo mode of this event. More...
void	set_mode (Mode mode)
	Set the undo mode of this event. More...
Engine &	engine ()

Protected Member Functions
	Event (Engine &engine, SPtr< Interface > client, int32_t id, FrameTime time)
	Event (Engine &engine)
	Constructor for internal events only.
bool	pre_process_done (Status st)
bool	pre_process_done (Status st, const Raul::URI &subject)
bool	pre_process_done (Status st, const Raul::Path &subject)
Status	respond ()
	Respond to the originating client. More...

Protected Attributes
Engine &	_engine
std::atomic< Event * >	_next
SPtr< Interface >	_request_client
int32_t	_request_id
FrameTime	_time
Status	_status
std::string	_err_subject
Mode	_mode

Detailed Description

An event (command) to perform some action on Ingen.

Virtually all operations on Ingen are implemented as events. An event has three distinct execution phases:

1) Pre-process: In a non-realtime thread, prepare event for execution 2) Execute: In the audio thread, execute (apply) event 3) Post-process: In a non-realtime thread, finalize event (e.g. clean up and send replies)

Member Enumeration Documentation

Mode

enum Ingen::Server::Event::Mode

strong

Event mode to distinguish normal events from undo events.

Execution

enum Ingen::Server::Event::Execution

strong

Execution mode for events that block and unblock preprocessing.

Member Function Documentation

pre_process()

virtual bool Ingen::Server::Event::pre_process ( PreProcessContext &  ctx )

pure virtual

Pre-process event before execution (non-realtime).

Implemented in Ingen::Server::Events::Delta, Ingen::Server::Events::DisconnectAll, Ingen::Server::Events::Delete, Ingen::Server::Events::Disconnect, Ingen::Server::Events::Connect, Ingen::Server::Events::CreatePort, Ingen::Server::Events::CreateBlock, Ingen::Server::Events::Get, Ingen::Server::Events::SetPortValue, Ingen::Server::Events::Copy, Ingen::Server::Events::Mark, Ingen::Server::Events::Move, Ingen::Server::Events::CreateGraph, and Ingen::Server::Events::Undo.

Referenced by Ingen::Server::PreProcessor::process().

execute()

virtual void Ingen::Server::Event::execute ( RunContext &  context )

pure virtual

Execute this event in the audio thread (realtime).

Implemented in Ingen::Server::Events::Delta, Ingen::Server::Events::DisconnectAll, Ingen::Server::Events::Delete, Ingen::Server::Events::Disconnect, Ingen::Server::Events::Connect, Ingen::Server::Events::CreatePort, Ingen::Server::Events::CreateBlock, Ingen::Server::Events::Get, Ingen::Server::Events::SetPortValue, Ingen::Server::Events::Copy, Ingen::Server::Events::Mark, Ingen::Server::Events::Move, Ingen::Server::Events::CreateGraph, and Ingen::Server::Events::Undo.

Referenced by Ingen::Server::PreProcessor::process().

post_process()

virtual void Ingen::Server::Event::post_process ( )

pure virtual

Post-process event after execution (non-realtime).

Implemented in Ingen::Server::Events::Delta, Ingen::Server::Events::DisconnectAll, Ingen::Server::Events::Delete, Ingen::Server::Events::Disconnect, Ingen::Server::Events::Connect, Ingen::Server::Events::CreatePort, Ingen::Server::Events::CreateBlock, Ingen::Server::Events::Get, Ingen::Server::Events::SetPortValue, Ingen::Server::Events::Copy, Ingen::Server::Events::Mark, Ingen::Server::Events::Move, Ingen::Server::Events::CreateGraph, and Ingen::Server::Events::Undo.

Referenced by Ingen::Server::PostProcessor::process().

undo()

virtual void Ingen::Server::Event::undo ( Interface &  target )

inlinevirtual

Write the inverse of this event to sink.

Reimplemented in Ingen::Server::Events::Delta, Ingen::Server::Events::DisconnectAll, Ingen::Server::Events::Delete, Ingen::Server::Events::Disconnect, Ingen::Server::Events::Connect, Ingen::Server::Events::CreatePort, Ingen::Server::Events::CreateBlock, Ingen::Server::Events::Copy, Ingen::Server::Events::Move, and Ingen::Server::Events::CreateGraph.

Referenced by Ingen::Server::PreProcessor::process().

is_prepared()

bool Ingen::Server::Event::is_prepared ( ) const

inline

Return true iff this event has been pre-processed.

Referenced by Ingen::Server::PreProcessor::event(), and Ingen::Server::PreProcessor::process().

time()

SampleCount Ingen::Server::Event::time ( ) const

inline

Return the time stamp of this event.

Referenced by Ingen::Server::PreProcessor::process(), Ingen::Server::PostProcessor::process(), set_mode(), and set_time().

set_time()

void Ingen::Server::Event::set_time ( SampleCount  time )

inline

Set the time stamp of this event.

References time().

Referenced by Ingen::Server::PreProcessor::process().

next() [1/2]

Event* Ingen::Server::Event::next ( ) const

inline

Get the next event to be processed after this one.

Referenced by Ingen::Server::PostProcessor::append(), Ingen::Server::PreProcessor::event(), Ingen::Server::PreProcessor::process(), and Ingen::Server::PostProcessor::process().

next() [2/2]

void Ingen::Server::Event::next ( Event *  ev )

inline

Set the next event to be processed after this one.

status()

Status Ingen::Server::Event::status ( ) const

inline

Return the status (success or error code) of this event.

get_mode()

Mode Ingen::Server::Event::get_mode ( ) const

inline

Return undo mode of this event.

Referenced by Ingen::Server::PreProcessor::process().

set_mode()

void Ingen::Server::Event::set_mode ( Mode  mode )

inline

Set the undo mode of this event.

References time().

Referenced by Ingen::Server::PreProcessor::event().

respond()

Status Ingen::Server::Event::respond ( )

inlineprotected

Respond to the originating client.

Referenced by Ingen::Server::Events::CreateGraph::post_process(), Ingen::Server::Events::SetPortValue::post_process(), Ingen::Server::Events::CreateBlock::post_process(), Ingen::Server::Events::CreatePort::post_process(), and Ingen::Server::Events::DisconnectAll::post_process().

---

The documentation for this class was generated from the following file:

• Event.hpp
