Base class for all Node models (BlockModel, GraphModel, PortModel). More...

#include <ObjectModel.hpp>

Inheritance diagram for Ingen::Client::ObjectModel:

Collaboration diagram for Ingen::Client::ObjectModel:

Public Member Functions
bool	is_a (const URIs::Quark &type) const

const Atom &	get_property (const Raul::URI &key) const
	Get a single property value. More...

void	on_property (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property is added. More...

void	on_property_removed (const Raul::URI &uri, const Atom &value)
	Hook called whenever a property value is removed. More...

const Raul::Path &	path () const

const Raul::Symbol &	symbol () const

SPtr< ObjectModel >	parent () const

bool	polyphonic () const

Node *	graph_parent () const

	INGEN_SIGNAL (new_child, void, SPtr< ObjectModel >)

	INGEN_SIGNAL (removed_child, void, SPtr< ObjectModel >)

	INGEN_SIGNAL (property, void, const Raul::URI &, const Atom &)

	INGEN_SIGNAL (property_removed, void, const Raul::URI &, const Atom &)

	INGEN_SIGNAL (destroyed, void)

	INGEN_SIGNAL (moved, void)

Public Member Functions inherited from Ingen::Node
Arcs &	arcs ()

const Arcs &	arcs () const

virtual uint32_t	num_ports () const

virtual Node *	port (uint32_t index) const

virtual const Resource *	plugin () const

virtual LilvInstance *	instance ()

virtual bool	save_state (const std::string &dir) const

virtual GraphType	graph_type () const =0

Raul::URI	base_uri () const

Public Member Functions inherited from Ingen::Resource
	Resource (const URIs &uris, const Raul::URI &uri)

Resource &	operator= (const Resource &rhs)

virtual const Atom &	set_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual const Atom &	set_property (const Raul::URI &uri, const URIs::Quark &value, Graph ctx=Graph::DEFAULT)
	Set (replace) a property value. More...

virtual bool	add_property (const Raul::URI &uri, const Atom &value, Graph ctx=Graph::DEFAULT)
	Add a property value. More...

virtual void	remove_property (const Raul::URI &uri, const Atom &value)
	Remove a property. More...

virtual void	remove_property (const Raul::URI &uri, const URIs::Quark &value)
	Remove a property. More...

virtual bool	has_property (const Raul::URI &uri, const Atom &value) const
	Return true iff a property is set with a specific value. More...

virtual bool	has_property (const Raul::URI &uri, const URIs::Quark &value) const
	Return true iff a property is set with a specific value. More...

void	set_properties (const Properties &p)
	Set (replace) several properties at once. More...

void	add_properties (const Properties &p)
	Add several properties at once. More...

void	remove_properties (const Properties &p)
	Remove several properties at once. More...

virtual void	set_uri (const Raul::URI &uri)

Properties	properties (Resource::Graph ctx) const
	Get all the properties with a given context. More...

const URIs &	uris () const

const Raul::URI &	uri () const

const Properties &	properties () const

Properties &	properties ()

Protected Member Functions
	ObjectModel (URIs &uris, const Raul::Path &path)

	ObjectModel (const ObjectModel &copy)

virtual void	set_path (const Raul::Path &p)

virtual void	set_parent (SPtr< ObjectModel > p)

virtual void	add_child (SPtr< ObjectModel > c)

virtual bool	remove_child (SPtr< ObjectModel > c)

virtual void	set (SPtr< ObjectModel > model)
	Merge the data of `o` with self, as much as possible. More...

Protected Member Functions inherited from Ingen::Node
	Node (const URIs &uris, const Raul::Path &path)

Protected Member Functions inherited from Ingen::Resource
const Atom &	set_property (const Raul::URI &uri, const Atom &value) const

Protected Attributes
SPtr< ObjectModel >	_parent

Protected Attributes inherited from Ingen::Node
Arcs	_arcs
	Graphs only.

Protected Attributes inherited from Ingen::Resource
const URIs &	_uris

Friends
class	ClientStore

Additional Inherited Members
Public Types inherited from Ingen::Node
enum	GraphType { GRAPH, BLOCK, PORT }

typedef std::pair< const Node , const Node >	ArcsKey

typedef std::map< ArcsKey, SPtr< Arc > >	Arcs

Public Types inherited from Ingen::Resource
enum	Graph { DEFAULT, EXTERNAL, INTERNAL }

Static Public Member Functions inherited from Ingen::Node
static Raul::URI	main_uri ()

static bool	uri_is_path (const Raul::URI &uri)

static Raul::Path	uri_to_path (const Raul::URI &uri)

static Raul::URI	path_to_uri (const Raul::Path &path)

Static Public Member Functions inherited from Ingen::Resource
static Raul::URI	graph_to_uri (Graph g)

static Graph	uri_to_graph (const char *uri)

static bool	type (const URIs &uris, const Properties &properties, bool &graph, bool &block, bool &port, bool &is_output)
	Get the ingen type from a set of Properties. More...

Detailed Description

Base class for all Node models (BlockModel, GraphModel, PortModel).

There are no non-const public methods intentionally, models are not allowed to be manipulated directly by anything (but the Store) because of the asynchronous nature of engine control. To change something, use the controller (which the model probably shouldn't have a reference to but oh well, it reduces Collection Hell) and wait for the result (as a signal from this Model).

Member Function Documentation

§ get_property()

const Atom & Ingen::Client::ObjectModel::get_property ( const Raul::URI & uri ) const

virtual

Get a single property value.

This is only useful for properties with a single value. If the requested property has several values, the first will be returned.

Reimplemented from Ingen::Resource.

Referenced by Ingen::Client::PortModel::on_property().

§ on_property()

void Ingen::Client::ObjectModel::on_property	(	const Raul::URI &	uri,
		const Atom &	value
	)

virtual

Hook called whenever a property is added.

This can be used by derived classes to implement special behaviour for particular properties (e.g. ingen:value for ports).

Reimplemented from Ingen::Resource.

Reimplemented in Ingen::Client::PortModel.

Referenced by Ingen::Client::PortModel::on_property().

§ on_property_removed()

void Ingen::Client::ObjectModel::on_property_removed	(	const Raul::URI &	uri,
		const Atom &	value
	)

virtual

Hook called whenever a property value is removed.

If all values for a key are removed, then value will be the wildcard.

This can be used by derived classes to implement special behaviour for particular properties (e.g. ingen:value for ports).

Reimplemented from Ingen::Resource.

§ set()

void Ingen::Client::ObjectModel::set ( SPtr< ObjectModel > o )

protectedvirtual

Merge the data of o with self, as much as possible.

This will merge the two models, but with any conflict take the value in o as correct. The paths of the two models MUST be equal.

Reimplemented in Ingen::Client::BlockModel.

References Ingen::Resource::set_property().

Referenced by Ingen::Client::PortModel::on_property(), and Ingen::Client::BlockModel::set().

The documentation for this class was generated from the following files:

ObjectModel.hpp
ObjectModel.cpp
